Creo Parametric 5.0: Surface Design - Paperback

by Ascent -. Center for Technical Knowledge (Author)

Creo Parametric 5.0: Surface Design focuses on the creation of complex geometry that cannot be created easily using solid features. It provides students with a basic understanding of surface modeling styles and extensive practices to practice the new functionality used to create complex geometry.

Creo Parametric 5.0: Surface Design was developed using Creo Parametric 5.0.3.0.

Topics Covered

• Surface Basics
• Reference Geometry
• Splines and Conics
• Creating Simple Surfaces
• Surface Operations
• Creating Surfaces from Boundaries
• Analysis Tools
• Advanced Surfaces (Curvature Continuous Surfaces, Ribbon Surface)
• Advanced Swept Surfaces
• Offset Surfaces
• Introduction to Data Exchange (Import Data Doctor)

Prerequisites

• Access to the Creo Parametric 5.0 software. The practices and files included with this guide might not be compatible with prior versions. Practice files included with this guide are compatible with the commercial version of the software, but not the student edition.
• Completion of Creo Parametric 5.0: Introduction to Solid Modeling and Creo Parametric 5.0: Advanced Part Design or equivalent Creo Parametric experience is recommended.
